Design and Build a Custom Gun Wall / Gun Room

The single stock shelves work well when you have a wider variety of rifle lengths and you need maximum vertical efficiency.

Construction:

Are you using existing walls or are you building new? Existing walls – Normal walls (studs and drywall) should be covered with 1/2″ or 3/4″ plywood. If building a new you can substitute plywood for drywall. – depending on the wall layout and other items (doors, windows, electrical) it may be beneficial to build the wall with drywall then cover the area for the gun wall with plywood.

Construction Note

The louvered panels attach to the plywood via 1″ drywall screws. There are holes punched every 2″, normally you will use 6 screws for the 16″ panels and 8-10 for the 36″ panels. If there are shelves that are holding a lot of weight (for example: full ammo cases) you may want to add additional screws to support the load.

Planning and layout for a gun wall

How many panels will fit? To determine the maximum number of panels that will fit use the formula: wall length in inches divided by 17.25 (the width of one panel) Our room dimensions Above is a drawing of the room we will turn into an armory. The right side of the room is open. We will build a wall with a secure double door system. This is the room with the gun storage system, workbench, wall built and double doors drawn in .

Let’s look at each wall:

Here we have a small drawing with the walls labeled and the back wall “A”, this has grid panels and our workbench. To calculate to a number of panels: the wall is 9′ = 108″ each grid panel is 17.25″ wide so 108 divided by 17.25 = 6.26 we can fit 6 panels on the wall. these are centered and our workbench sits in front. Wall “B” we use the same process here: wall – 18′ 6″ = 222″ — 222 / 17.25 = 12.86 so we use 12 panels. Wall “C” On this wall we are using hardwood between the panels. This gives the system a softer and warmer look. We installed the plywood, then used 1×4 hardwood to create the framework, then the panels were attached in the center sections. Normally we would do all walls the same, however, we wanted to use this room as a showpiece for different styles and looks.

System Height

Determine what height is right for your wall. There are two lengths of panels, 16″ high and 36″. Two rows of the large panels fit most applications. This yields 6′ of vertical grid wall. In our room, we start the bottom panels 14″ off the floor. The bottom row of rifles sits on the Stock bases on the floor. 14: off puts to the top of the system at 86″ in a standard room with 8′ ceiling the results look good and work well. You can also start panels on the floor, use Two 36’s and one 16″ panel this will give you a total height of 88″. With this option, you will have the ability to use bins, shelves, and other accessories for the floor up. In the image above we show a 72″ high system 14″ off the floor. There are 24 rifles stored vertical and 3 horizontal. The rifle barrels at the top can be taller than the system. Next, we show floor to ceiling using 3 panels.

Option:

use 2 x 12 lumber or build a wood base on the floor for stock bases. This gets the rifles off the floor. Painting the wood Black or an accent color will give you a nice finished look.

Plywood

Plywood is placed over the drywall and painted (we recommend dark grey or black) so you can attach the panels. We use 1″ drywall screws to secure the panels to the plywood. The screws will go through the plywood and into the drywall. If you want to option to remove or move the gun storage system with minimal impact on the wall. Install the plywood with furring strips to give you enough space for the screw. This is also the method for installing a gun storage system into brick or concrete walls. For brick or concrete walls use furring strips

Mounting the panels.

In a 2 panel high system, we start with the top panels. measure the height where you want the bottom. Snap a line where the bottom will be, make sure it is level. We normally will screw a temporary ledger board onto the plywood at the line so to support the panel during install. When installing screws into panels, make sure to center the screws in the holes. If a screw is off-center it can push the panel off the line as it is tightened. – quick fix: if a screw is off a bit, leave it loose until the other screws are seated then tighten this will keep the panels straight. We install screws every 3 -4 louvers and every 2-3 rows. adding a few screws to the panel joints will keep things straight and clean. When the panels are installed you can start adding components and firearms. There are unlimited options as far as how you store things! Gun Room Reloading bench Reloading dyes stored in the gun room. Gun Smith bench in a gun room

SecureIt Gun Room Overview:
